Carolina Chickadee: Second Record for Ontario and Canada

Brandon R. Holden and David M. Bell




Introduction

On 13 May 2013 at roughly 0640 EDT, we were birding just south of the Sparrow Field at Point Pelee National Park, Essex, when we spotted an unusual chickadee in close proximity to a typical Black-capped Chickadee (Poecile atricapilla). Our attention was immediately drawn to its grayscale, low-contrast appearance and slightly atypical GISS (general impression of size and shape). Our impression was that this was a Carolina Chickadee (Poecile carolinensis), yet both of us knew that there was only one previously accepted record of this species for Ontario and Canada: a single bird observed on 18 May 1983 at Long Point (Tip), Norfolk (Weir 1983, James 1984). This prompted us to begin taking sample photographs in an attempt to properly document the individual. Although we each had previous experience with Carolina Chickadee in the species core range, the identification is notoriously difficult (Kaufman 1990). After several minutes of observation, the bird remained silent and we continued onwards with the mornings birding.

Later that day at the parks visitor centre, we queried the available references for new insight into this difficult identification. The popular field guides focused heavily on two features: a white vs gray nape and brighter vs paler edging on the flight feathers for Black-capped and Carolina, respectively (Sibley 2000, Peterson 2008). Review of our photographs revealed a bird with faint feather edging, suggesting Carolina, but inconclusive as the lighting and angle in various photographs seemed to change the appearance dramatically. Feeling stuck, we did little more in the short term, other than Holden posting some photos with a request for opinions on his web log (Holden 2013a).
We continued to bird in the Point Pelee area over the next two days and discussed the sighting with other birders. On 14 May, Peter S. Burke commented that the amount of white edging on the greater coverts was an excellent mark for helping to identify individuals of this complex, and that the bird in our photographs looked much better for Carolina. On the morning of 15 May, we were witnessing a moderate reverse migration  at the Tip of Point Pelee when various observers (including Peter S. Burke) began arriving and informed us that they too had seen the subject chickadee at various times around the Tip area. All agreed that it was easily detected among Black-capped Chickadees due to its relatively distinctive appearance.

At roughly 0800 EDT on 15 May, we had the opportunity to observe the subject chickadee at the extreme Tip with two typical Black-capped Chickadees. Once again it stood out immediately due to its greyscale, low contrast appearance and different GISS. It was present for a short period of time before flying northwards away from the Tip. Alan Wormington had independently recognized the bird from some distance to the south and simultaneously pursued the bird northwards. As various observers moved north, multiple Black-capped Chickadees were detected around the Point causing considerable confusion. Regrettably the subject chickadee was not observed again.

After additional information from the 15 May sighting was posted online (Holden 2013b), we received photographs of the subject bird taken just north of the Tip of Point Pelee on 12 May by Hayden J. Bildy. He was birding with R. Gordon Payne at the time, who also observed the bird (Burrell and Charlton 2015).

Over the next several months, we conducted extensive research on this difficult identification. Presented below are the results of that research and why it supports the identity of this bird as a Carolina Chickadee.


Identification

In this section, we highlight the following identification criteria, derived from numerous sources: head size and shape, bill size and shape, bib size and shape, nape colouration, cheek patch vs breast colouration, secondary and tertial edging, greater coverts base shade and edging, tail feather edging and tail length/wing chord ratio. Regrettably no vocalizations were heard by any observers. Our analysis compares the Point Pelee individual with the criteria for known Carolina Chickadee and Black-capped Chickadee. A detailed comparison of each trait with photo examples was submitted to the OBRC (Holden 2013b, Holden 2013c, Holden and Bell 2014) and is archived at the Royal Ontario Museum (ROM).

Head Size and Shape: A review of many photographs of Black-capped and Carolina chickadees showed that Carolina frequently appears to have a smaller and rounder head in contrast to Black-capped Chickadee which frequently shows a proportionately larger head, appearing as a horizontal oval in shape. The Point Pelee individual was a better match to known Carolina Chickadees (Figs. 1, 2).

Bill Size and Shape: This is difficult to properly quantify from photos. After reviewing hundreds of Black-capped Chickadee photographs from southern Ontario, our impression was that the Point Pelee bird had a smaller and shorter bill (Figs. 1, 2). It does not appear to show any dramatic differences from known Carolina Chickadees when compared to photographs from various online sources. Pyle (1997) lists the exposed culmen of Black-capped as measuring 7.6-10.5mm and of Carolina as 6.6-9.5mm.

Bib Size and Shape: In some identification guides, Carolina Chickadee is described as having a smaller and more sharply defined bib than Black-capped Chickadee (e.g., National Geographic 2002). Approximately 100 photos were taken of the Point Pelee individual by the authors, which revealed a remarkable range in bib size and shape. This range was most pronounced during periods of activity, with the bird stretching or twisting its neck to obtain food or move to a new perch. During the few moments when the bird was at rest, the birds bib size and shape was well defined and small and was a better match for Carolina Chickadee than examples of Black-capped Chickadee (Fig. 3).

Nape Colouration: Although this character is frequently referenced in field guides (e.g., Peterson 2008), we had a difficult time assessing this feature when using images. Variations in exposure settings yielded results from pure white to neutral gray. We felt that this feature was not useful when studying photographs although perhaps it would be a better feature when scrutinized with a live specimen in hand.

Cheek Patch vs Breast Colouration: During formal review of the record by the OBRC, Peter S. Burke identified a potential feature of Carolina Chickadee on the Point Pelee individual stating that the breast appeared to be a duller gray than the bright white cheek patches (Sibley 2014). Photos of Black-capped Chickadee often show a breast that is as bright/white as the cheek patches. This feature was not examined on skins or as extensively with photographs as other field marks noted here, yet it appears to support the identification of the Point Pelee bird as a Carolina Chickadee.

Secondary and Tertial Edging: Examination of photographs online and of the Point Pelee bird  shows that this feature is variable depending on angle and camera settings, even with a single individual. Carolina Chickadee is reported to show a more muted pattern, compared to Black-capped Chickadee (Sibley 2000). When considering the approximately 100 images of the Point Pelee individual, our overall impression was of a bird that fell within the range for Carolina Chickadee (Fig. 2), but appearing as an outlier in the variation observed in Black-capped Chickadee.

Greater Covert Base Shade: A field mark rarely referenced is the base shade or colour of the centres of the greater primary and secondary coverts. It is reported to be gray in Carolina Chickadee, whereas in Black-capped Chickadee it is black (Crossley 2011). The greater coverts in photographs of the Point Pelee individual in which the bird had spread wings are a medium gray, matching Carolina Chickadee (Fig. 4), although the sample size was small. Holden studied nearly 300 skins of both species at the ROM and found that this feature is not reliable in direct comparison. We presume it is simply a difference in impression, with Black-capped appearing more contrasting than the uniform gray of Carolina.

Greater Covert Edging: Another field mark that is occasionally referenced is the contrasting white edges to the greater coverts of Black-capped Chickadee whereas Carolina shows a uniform gray edge. While it appears possible for Black-capped Chickadee to lose these white edges due to feather wear (especially in spring as chickadees do not do a pre-alternate molt (Pyle 1997)), our examination of photographs has shown it to be rare. The Point Pelee individual shows a uniform gray edge on all feathers on each wing, matching known examples of Carolina Chickadee (Fig. 5).

Rectrices: Pyle (1997) states that Black-capped Chickadee can be separated from Carolina Chickadee by the [presence of] white edging to the outer rects. Despite only retaining three rectrices, the Point Pelee individual clearly shows a white edge, which was originally identified as a problem in the identification of this bird as a Carolina Chickadee. We set out to confirm the validity of this feature and discovered that many Carolina Chickadees from the central and northern parts of the species range show white edges on the rectrices (Holden 2013d). Thus the white edging on the Point Pelee bird appears well within the variation shown by pure Carolina Chickadee and does not contradict that identification. Review of specimens at the ROM also showed that this is a feature frequently shown by Carolina Chickadee including the first provincial record (Holden 2014). Review of Black-capped Chickadee photographs has shown a bolder and more prominent edge to the rectrices than Carolina Chickadee.

Tail Length/Wing Chord ratio: Pyle (1997) states that tail length is the most useful character in separating Black-capped from Carolina chickadees. Although impossible to accurately measure without a bird in-hand, tail length relative to wing chord can be useful as the tail/wing ratio can then provide further means for separation: 0.886-1.032 (usually >0.9) for Black-capped, 0.819-0.922 (usually <0.9) for Carolina (Pyle 1997:335). Using photographic samples of 10 known Black-capped Chickadees, 10 known Carolina Chickadees and 15 of the Point Pelee bird, we set out to see if the tail/wing ratio could be useful in this case. For this analysis to be conducted, photos that showed the bird in profile were chosen because the wing and tail were held at approximately the same angle to the photographer. We used the ruler tool in Adobe Photoshop CS4 to determine lengths of wing chord and tail for each photo. These values were then inserted into a Microsoft Excel spreadsheet which calculated the tail/wing ratio (tail length divided by wing chord). We then sorted the values into Black-capped Chickadee (BCCH), Carolina Chickadee (CACH) or intermediate (Figure 6).

Four (of 10) photos of Black-capped Chickadee resulted in values that were within the overlap range, but still above the usual cut-off of 0.9. Three (of 10) photos of Carolina Chickadee resulted in values that were similarly within the overlap range (0.886-0.922), with one being above the usual cut-off of 0.9 but still within variation for Carolina Chickadee (Figure 1). All other photos fell within the expected range for their respective species. The 15 photos of the Point Pelee bird showed an average tail/wing ratio of 0.8667 and a standard deviation of 0.0086 (1%) showing that measuring error (possibly due to differences in posture) was minimal. The same average and standard deviation statistics cannot be applied to the known photos of either species as they represent different individuals. The values obtained for the Point Pelee bird are all within the variation for Carolina Chickadee, and more importantly, all are below the minimum ratio for Black-capped Chickadee.

General Impression (GISS): A final thought, which is once again difficult to quantify, we and other observers were readily able to detect the bird when it was present, due to its a distinctive GISS. The general colour, low contrast appearance and atypical shape combined to produce a very noteworthy individual. Many field marks presented here were unknown to us at the time of observation, and have been correlated with the Point Pelee bird only after additional research was conducted.

Conclusion: While many features listed above are overlapping, there is no single feature present on the bird that is outside the range of Carolina Chickadee.





Subspecific Identity

Pyle (1997) noted that geographic variation in Carolina Chickadee is weak and clinal where the ranges of subspecies meet. Mostrom et al. (2002) list four subspecies, following Snow (1967) and Philips (1986) which are detailed below.

P. c. atricapilloides     A large, gray subspecies that occurs from south Kansas through central Texas.
P. c. agilis                   A medium sized, gray subspecies occurring from south Arkansas to southeast Texas and south Louisiana.
P. c. carolinensis         A small, dark gray subspecies with an olive tinge occurring from north Arkansas-southeast Louisiana through to southeast Virginia-Florida. Synonymous with P.c. impiger.
P. c. extima                 A large and slightly more colourful subspecies, noted as having more extensive white on the secondaries, sides and flanks. This subspecies occurs north of P.c. carolinensis west to eastern Missouri. Subspecific name formerly extimus (AOU 2000).

We compiled approximately 300 photos of Carolina Chickadees from various online and published sources. Study of P.c. carolinensis reveals the strongest differences from the Point Pelee individual, being darker and less contrasting overall. An examination of birds from within the ranges of P. c. atricapilloides and P. c. agilis also showed differences, especially as few individuals showed white on their outer retrices as well as showing a more uniform gray appearance overall. The white on the outer rectrix of the Point Pelee Carolina Chickadee matches known individuals from the northern tier of the species range such as Illinois, Ohio, Indiana and Pennsylvania all of which would fall within the range of P. c. extima. After further examination, there were no differences between the Point Pelee bird and photos of birds within the range of P. c. extima; leading us to believe that it is the appropriate subspecific identification for this bird.


Hybridization

Hybrids between the Black-capped and Carolina Chickadees have been detected wherever the contact zone between them has been studied (Sibley 2009). The same article states that hybrids are less fit than pure birds, leaving hybrid populations small and stable. Given that the Point Pelee bird shows no outward sign of hybridization in the form of intermediate characteristics of head size and shape, bill size and shape, bib size and shape, cheek patch vs breast colouration, secondary and tertial edging, greater coverts base shade and edging, tail feather edging and tail length/wing chord ratio; the authors felt it was reasonable to identify it as a pure Carolina Chickadee.


Discussion

Canadas first Carolina Chickadee record, initially listed as P. c. impiger by James (1984), was later published as the synonymous subspecies P. c. carolinensis by Gustafson (1987). After a thorough examination of the specimen, Parkes (1988) changed the subspecific identity to P. c. extimus (now P. c. extima), which is the same as our identification of the Point Pelee individual. A query of the eBird database shows the stable northern boundary of the Carolina Chickadee range surprisingly close to our observations at Point Pelee, measured to as little as 80km SSW at Findlay, Ohio (eBird 2014). With other records of vagrants occurring in northern Illinois (American Ornithologists Union 1998), southeast Michigan (Reinoehl 1997), northern Ohio (Williams 1944) and western New York (Bent 1946), the Carolina Chickadee has a well-established pattern of short-distance vagrancy in the Great Lakes region. The contact zone between Carolina and Black-capped chickadees has been slowly moving northwards (Taylor et al. 2014) and has a female biased dispersal. While impossible to know, the quiet nature of the Point Pelee bird may have been due to the possibility that it was a wandering female. It is not outlandish to suggest that future records will materialize in southern Ontario. Perhaps the only limiting factor is the high degree of difficulty in detecting, identifying and properly documenting any future observations.

The sighting from 12-15 May 2013 at Point Pelee National Park was accepted by the OBRC as the second record for Ontario and Canada (Burrell and Charlton 2015).

Side Note. A possible occurrence of Carolina Chickadee in Ontario has been published (Jarvis 1965), based on song only, the bird was never seen. However, this report was not accepted by the OBRC (Wormington 1985).


Photo: David Bell


Literature Cited

American Ornithologists Union. 1998. Check-list of North American Birds. Seventh Edition. American Ornithologists Union, Washington, D.C. 829pp.
American Ornithologists' Union. 2000. Forty-second supplement to the American Ornithologists' Union check-list of North American birds. Auk 117:847-858.
Bent, A.C. 1946. Life histories of North American Jays, Crows and Titmice, pt. 1. US National Museum Bulletin 191.
Burrell, M.V.A. and B.N. Charlton. 2015. Ontario Bird Records Committee report for 2014. Ontario Birds 33:50-81.
Crossley, R. 2011. The Crossley ID Guide Eastern Birds. Princeton University Press. Princeton, New Jersey. 530pp.
Gustafson, M. 1987. One fewer U.S. endemic [letter to the editor]. Birding 29:14.
James, R.D. 1984. Ontario Bird Records Committee report for 1983. Ontario Birds 2:13-23.
Jarvis, J.D. 1965. A possible occurrence of the Carolina Chickadee (Parus carolinensis) in southwestern Ontario. Ontario Field Biologist 19:42.
Kaufman, K. 1990. A field guide to advanced birding: birding challenges and how to approach them. Houghton Mifflin Co. Boston, Massachusetts. 299pp.
Mostrom, A.M., R.L. Curry and B. Lohr. 2002. Carolina Chickadee (Poecile carolinensis), The Birds of North America Online (A. Poole, Ed.). Ithaca: Cornell Lab of Ornithology; Retrieved from the Birds of North America Online at http://bna.birds.cornell.edu/bna/species/636
National Geographic. 2002. Field Guide to the birds of North America Fourth Edition. National Geographic Society. Washington, D.C. 480pp.
Parkes, K.C. 1988. The Ontario specimen of Carolina Chickadee. Ontario Birds 6:111-114.
Peterson, R.T. 2008. Field Guide to the Birds of North America. Houghton Mifflin Co., Boston, Massachusetts. 532pp.
Phillips, A.R. 1986. The known birds of North and Middle America, Pt. 1. Hirundinidae to Mimidae: Certhiidae. Denver Museum of Natural History. Denver, Colorado. 259 pp.
Pyle, P. 1997. Identification Guide to North American Birds Part I. Braun-Brumfield Inc. Ann Arbour, Michigan. 732pp.
Reinoehl, J. 1997. Actions of the Michigan Bird Records Committee for 1995. Michigan Birds and Natural History 4:117-124.
Sibley, D.A. 2000. The Sibley Guide to Birds. Alfred A. Knopf, Inc. New York. 546pp.
Sibley, D.A. 2014. The Sibley Guide to Birds, Second Edition. Alfred A. Knopf, Inc. New York. 599pp.
Snow, D.W. 1967. Check-list of Birds of the World. Museum of Comparative Zoology, Massachusetts. 12:70-124.
Taylor, S.A., T.A. White, W.M. Hochachka, V. Ferretti, R.L. Curry and I. Lovette. 2014. Climate-Mediated Movement of an Avian Hybrid Zone. Current Biology 24:16.
Weir, R.D. 1983. Ontario region. American Birds 37:863-867.
Williams, A.B. 1944. The Cleveland Bird Calendar. The Kirtland Bird Club. Cleveland, Ohio. 10pp.
Wormington, A. 1985. Ontario Bird Records Committee report for 1984. Ontario Birds 3:2-17.


Other Reference Material

eBird. 2014. eBird database accessed by Brandon Holden. February 2014. Carolina Chickadee dataset for North America, all years.
Holden, B.R. 2013a. Pelee May 13 !! Slow... Slow slow slow.. and FANTASTIC [Web log entry] PeregrinePrints.com ... Blog. 13 May 2013. (http://www.blog.peregrineprints.com/2013/05/pelee-may-13-slow-slow-slow-slow-and.html) Accessed 5 February 2014.
Holden, B.R. 2013b. “Pelee Birds May 15!” [Web log entry] PeregrinePrints.com ... Blog. 15 May 2013. (http://www.blog.peregrineprints.com/2013/05/pelee-birds-may-15.html) Accessed 2 February 2016.
Holden, B.R. 2013c. A silly number of Chickadee Pictures [Web log entry] PeregrinePrints.com ... Blog. 28 May 2013. (http://www.blog.peregrineprints.com/2013/05/a-silly-number-of-chickadee-pictures.html). Accessed 10 April 2014.
Holden, B.R. 2013d. “CACH w/ White in the Tail” [Web log entry] PeregrinePrints.com … Blog. 5 October 2013. (http://www.blog.peregrineprints.com/2013/10/cach-w-white-in-tail.html) Accessed 6 April 2015.
Holden, B.R. 2014. “The Long Point specimen of Carolina Chickadee!!!” [Web log entry] PeregrinePrints.com … Blog. 14 June 2014. (http://www.blog.peregrineprints.com/2014/06/the-long-point-specimen-of-carolina.html) Accessed 6 April 2015.Holden, B.R. and D.M. Bell. 2014. Ontario Bird Records Committee Report: Carolina Chickadee Identification Support. Unpublished material. 22pp. Sibley, D.A. 2009 Identification: Black-capped vs. Carolina Chickadee [Web log entry]
Sibley Guides Blog. 9 November 2009. (http://www.sibleyguides.com/bird-info/black-capped-chickadee/black-capped-carolina-chickadee/) Accessed 5 March 2014.



Wednesday, June 8, 2016

Oriole ID


Is hard. Sometimes.














I mean, it's a female Orchard Oriole - right? Pelee Island on May 7th... Looked large to those of us who were watching...

Then we have Point Pelee - May 24th:










Could this bird have some Bullock's in it? (Eg,/ Hybrid?) Or can Baltimore look like this? I had a pretty pale/gray female Baltimore on Pelee Island (no pics) but something above the concentration of colour (eg,/ bright undertail coverts) contrasting with the gray belly/underwing seemed more BUOR to me. Also has a bit of that eyeline...

Sunday, June 5, 2016

Bicknell's Thrush does not exist



Had this wee little Thrush at Lighthouse Point near the end of my Pelee Island trip. Clearly a Gray-cheeked Thrush - but it really was a tiny little bugger... Of course this reminded me of Bicknell's Thrush - but as far as I'm concerned - it's not really a "good" species to identify...

Which bugs me... Do you know why?

Because I want to identify everything I see - and no matter how many times I read up on BITH vs. GCTH (including some recent voting on the OBRC) - I get NOWHERE. We barely learned of a method for separating HERMIT Thrush from BITH... Never mind Gray-cheeked...




So there you have it. My little "Gray-cheeked" Thrush with some rufous tail-markings... zzzzz...
I can't help but think of the select few birders who are excited about identifying all obvious markings/plumages/subspecies - rather than just a species level identification (eg,/ Birder X enjoys looking for "Oregon" Junco - even if it's not considered a species) - Whereas Bicknell's Thrush enjoys full species status, and seems to be a dead end on possible identification...
Recently there was a "European/Siberian" Whimbrel in Michigan - and I couldn't help but chuckle. People freaking LOVE Whimbrel to begin with - and here's this MEGA rare Eurasian variety flying around ---- with a host of distinctive markings --- and you hardly hear a peep!




Anyways, that's enough... This little bit of a reddish tail makes me wonder if it's the "Newfoundland" subspecies.. Ugh.











Thursday, June 2, 2016

May 11th (crazy day) - Scarlet Tanager photography



Couldn't say no to the red guys... Would never get tired photographing them. A great mix of challenge (the reds) with fun (reasonably approachable).

Pelee Island - May 11th - Fish Point - Evening - 2016 - woot
